ISO Chemical Equipment Industrial Air To Water Heat Exchanger

Chemical Equipment Heat Exchanger Water To Air

ISO Chemical Equipment

Industrial Air To Water Heat Exchanger

Place of Origin:

CHINA

Brand Name:

ATET

Certification:

ISO

Request A Quote

ISO Chemical Equipment Industrial Air To Water Heat Exchanger

Product Details

Equipment Name:

Air Preheater

Equipment Model:

STHL-YR260/0.6

Quantity/set:

One

Air Flow:

260 Nm3/min

Design Pressure:

0.6 Mpa

Design Temperature:

200 °C

Heat Exchange Medium:

Pressurized Air

Heat Exchange Mode:

Tubular Exchanger

Highlight:

Chemical Equipment Heat Exchanger Water To Air

ISO Chemical Equipment

Industrial Air To Water Heat Exchanger

Payment & Shipping Terms

Payment Terms

L/C, D/A, D/P, T/T, Western Union, MoneyGram

Customizable Heat Exchanger for Your Specific Requirements

Get Best Price

Versatile Gas Heater for Various Applications Get Warm Anywhere Anytime

Get Best Price

Gas water heat exchanger in the biological fermentation industry

Get Best Price

Air Pretreatment System

Get Best Price

+86-18163333313

wh@whatet.com

86-27-85887785

Contact Now

Product Description

Heat Exchanger Air To Water Heat Exchanger

INTRODUCTION

After the compressor does mechanical work to reduce its own volume and increase the pressure, it is called compressed air, which is an important power source. According to the data of "Analysis Report on Production and Marketing Demand and Transformation and Upgrading of China's Compressed Air Drying and Purification Industry", compressed air is the second largest power energy source after electricity, and its application range covers petroleum, chemical, metallurgy, electric power, machinery, light industry, textile, automobile manufacturing, electronics, food, medicine, biochemistry, national defense, scientific research and other industries and departments.

USED

The air pre-cooler developed by our company is mainly used in biological fermentation, medicine, chemical industry and other fields, and the products adopt a unique spiral counter-current heat exchange device, polymer material dewatering film technology, cyclone separation high-efficiency separation device, no air consumption drainage and other technologies, so as to solve the traditional low heat exchange efficiency and air pressure resistance Big. A series of problems such as large pressure drop and unclean water separation in the air have greatly improved the heat exchange efficiency and stability of the unit.

Heat exchanger	SEASON	Summer	Winter
	Cryogenic air inlet temperature°C	25	25
	Cryogenic air outlet temperature °C	40±5	40±5
	Heating heat kW	845	845
	High temperature air inlet temperature°C	130	80
	High temperature air outlet temperature°C	120	70
	Relative humidity %	<60	<40
Heat exchange area m2		150
Compressed air inlet and outlet pipe diameter mm		DN450
Pressure drop		2560
Material quality		304
Working		Continuous working
Installation		Integral skidding
