| Place of Origin: | CHINA |
|---|---|
| Brand Name: | ATET |
| Certification: | ISO |
| Minimum Order Quantity: | 1T |
| Price: | 150USD/T--650USD/T |
| Packaging Details: | 20KG/BAG, 25KG/BAG , 50KG/BAG, 500KG/BAG, 550KG/BAG, 600KG/BAG |
| Delivery Time: | 7-10 DAYS AFTER PAYMENT |
| Payment Terms: | T/T, L/C, D/A, D/P, Western Union, MoneyGram |
| Supply Ability: | 3000T/MONTH |
| Appearance: | Brown Powder | PH Value: | 7-9 |
|---|---|---|---|
| Dry Matter: | 93% Min | Moisture: | 7.0% Max |
| Lignosulphonate: | 60% Min | Total Reducing Matter: | 4.0% Max |
| Inorganic Salt （Na₂SO₄）: | 2.0% Max | Water Insoluble Matter: | 3.0% Max |
| CAS: | 8061-51-6 | HS CODE: | 3804000090 |
| High Light: | Sodium Lignosulfonate Expansion Agent,Expansion Agent Additive,Organic Sodium Lignosulfonate |
||
Sodium lignosulfonate used as organic expansion agent for the negative electrode of lead-acid battery
Sodium Lignonsulphonate :
A small amount of additives must be added to the negative activation substance of lead-acid battery, which is called expansion agent. Expansion agent has two aspects of the role: (1) can prevent the negative active material due to large specific surface area, thermodynamic instability, recrystallization in the process of charging and discharging, so that the specific surface area is constantly reduced, so that the negative active material loss of porosity and capacity decline, ultimately leading to battery failure; ② Depassivation under high rate discharge, low temperature and high acid concentration. The use of expansion agent can obviously increase the cycle charge and discharge times of the battery, improve the low temperature discharge capacity of the tube battery, improve the charge acceptance capacity, increase the negative active material surface area and stabilize its structure.
Sodium lignosulfonate is a widely used organic expansion agent.
The active material of lead-acid battery electrode is composed of lead compound or metal lead particles as the skeleton, which is surrounded by pores of various shapes. When the battery is charged and discharged, it is filled with electrolyte in the pores. The pores of active substances are the migration channel of electrolyte, which determines the existence state, quantity and proportion of electrolytic liquid phase. The number, shape and arrangement of pores directly affect the performance of the battery. In lead-acid batteries, on the one hand, sodium lignosulfonate combines with lead ions in solution to form lead lignosulfonate, which makes lead lignosulfonate molecules coagitate and cement together. On the other hand, lignosulfonic acid is adsorbed on the surface of PbO particles, promoting the adhesion and agglomeration of lead oxide particles, and finally forming a stable aggregation structure with certain pores, which ensures the charge-discharge performance of the battery.
| NO | Index items | Standard value | Test Results |
| 1 | Appearance | Brown powder | Meets the requirement |
| 2 | PH Value(1% soluble) | 7-9 | 8.8 |
| 3 | Dry matter | 93%min | 93.50 |
| 3 | Moisture | 7.0%max | 6.5 |
| 4 | lignosulphonate | 60%min | 61.40 |
| 5 | Total reducing matter | 4.0% max | 2.3 |
| 6 |
Inorganic salt (Na₂SO₄) |
2.0%max | 0.5 |
| 7 | Water insoluble matter | 3.0%max | 1.78 |
| 8 |
Calcium Magnesium General quantity |
0.5%max | 0.25 |
| 9 | Viscosity(20% aqueous solution 18-20℃) | 7-10 | 8.7 |
FAQ:
Q1. Which payment is available for your company?
Re: T/T, L/C, D/A, D/P, Western Union, MoneyGram
Q2. How can I get the sample?
Re: We provide you free sample. But you should pay for the postage. When we have a formal transaction, we will refund the postage of this sample.
Q3. How can you guarantee the goods you offer is qualified?
Re: We can provide sample, COA, MSDS and etc to help you insure the quality. And we promise every batch of product will be tested in the factory, and they can only leave the factory after the quality is qualified.
Q4. How can I get your best price?
Re: We will provide you timely market information and the fluctuation trends of raw material to help you determine the mos
